35
7217395.01 - en
INSTRUCTIONS PERTAINING TO THE INSTALLER
This natural draught boiler is intended to be connected only to a ue shared between multiple dwellings in existing buil-
dings that evacuates the residues of combustion to the outside of the room containing the boiler. It draws the combustion
air directly from the room and incorporates a draught diverter. Due to lower efciency, any other use of this boiler shall be
avoided and would result in higher energy consumption and higher operating costs.
This boiler is designed to heat water at a lower than boiling temperature at atmospheric pressure. The boiler must be
connected to a central heating system and to a domestic hot water supply system in compliance with its performances
and output power.
Have the boiler installed by a Qualied Service Engineer and ensure the following operations are accomplished:
a) careful checking that the boiler is t for operation with the type of gas available. For more details see the notice on the
packaging and the label on the appliance itself.
b) checking the boiler has a x external ue pipe which diameter has not to be less than the draught diverter’s collar
dimension.
c) make sure that the ue terminal draft is appropriate and that the terminal is not obstructed.
d) careful checking that, in case the ue has been connected to pre-existing ue ducts, thorough cleaning has been carried
out in that residual combustion products may come off during operation of the boiler and obstruct the ue duct.
To ensure correct operation of the appliance and avoid invalidating the guarantee, observe the following precautions:
1. Hot water circuit:
1.1. If the water hardness is greater than 20 °F (1 °F = 10 mg calcium carbonate per litre of water) a polyphosphate or
comparable treatment system responding to current regulations.
1.2. Domestic Hot Water circuit must be thoroughly ushed after the installation of the appliance and before its use.
1.3. The materials used for the domestic hot water circuit of the product comply with Directive 98/83/EC.
2. Heating circuit
2.1. new system
Before proceeding with installation of the boiler, the system must be cleaned and ushed out thoroughly to eliminate
residual thread-cutting swarf, solder and solvents if any, using suitable proprietary products.
To avoid damaging metal, plastic and rubber parts, use only neutral cleaners, i.e. non-acid and non alkaline. The
recommended products for cleaning are:
SENTINEL X300 or X400 and FERNOX heating circuit restore. To use this product proceeding strictly in accordance
with the maker’s directions.
2.2. existing system
Before proceeding with installation of the boiler, the system must be cleaned and ushed out to remove sludge
and contaminants, using suitable proprietary products as described in 2.1.
To avoid damaging metal, plastic and rubber parts, use only neutral cleaners, i.e. non-acid and non-alkaline such
as SENTINEL X100 and FERNOX heating circuit protective. To use this product proceeding strictly in accordance
with the maker’s directions.
Remember that the presence of foreign matter in the heating system can adversely affect the operation of the
boiler (e.g. overheating and noisy operation of the heat exchanger).
Failure to observe the above will render the guarantee null and void.
The following remarks and instructions are addressed to Service Engineers to help them carry out a faultless installation. In-
structions regarding lighting and operation of the boiler are contained in the ‘Instructions pertaining to the user’ section.
Note that installation, maintenance and operation of the domestic gas appliances must be performed exclusively by quali-
ed personnel in compliance with current standards.
Please note the following:
* This boiler can be connected to any type of double- or single feeding pipe convector plates, radiators, thermoconvec-
tors. Design the system sections as usual though taking into account the available output / pump head performances,
as shown in section 23.
* Do not leave any packaging components (plastic bags, polystyrene, etc.) within children’s reach as they are a potential
source of danger.
* Initial lighting of the boiler must be effected by a Qualied Service Engineer.
Failure to observe the above will render the guarantee null and void.
11. GENERAL INFORMATION
12. INSTRUCTIONS PRIOR TO INSTALLATION
