4-1
Confidential
CHAPTER 4 ADJUSTMENTS AND UPDATING OF SETTINGS,
REQUIRED AFTER PARTS REPLACEMENT
1. IF YOU REPLACE THE MAIN PCB ASSY
<What to do when replacing the main PCB ASSY>
• Rewriting the Firmware (Main Program)
• Setting the default paper size
• Setting the serial number
• Inputting the adjusted value of the laser unit
<What you need to prepare>
(1) A USB cable
(2) Computer (Windows
®
XP or later)
Create folder, for example "hl2200" folder on the C drive.
(3) Service Setting Tool (brusbn.zip)
Copy it into the "hl2200" folder that has been created on the C drive. Extract the copied
file and run "BrUsbsn.exe" file by double-clicking.
(4) Download Utility (FILEDG32.EXE)
Copy it into the "hl2200" folder that has been created on the C drive.
(5) Maintenance Driver (MaintenanceDriver.zip)
If Maintenance Printer Driver is not installed to your PC, copy it into the "hl2200" folder
that has been created on the C drive. Extract the copied file. (Refer to “INSTALLING
THE MAINTENANCE PRINTER DRIVER” in APPENDIX 3.)
(6) Firmware
(7) Setting file of the default paper size
DefaultPaperA4.pjl (A4 size)
DefaultPaperLtr.pjl (Letter size)
DefaultPaperIsr.pjl (A4 size, Israeli font for Israel)
Note:
• Since the counters are reset when the main PCB ASSY is replaced, the consumables
and/ or periodical replacement parts might reach the end of the life before the
message is displayed.
Main Program :
LZXXXX_$.blf
LZXXXX: First six digits are a parts number of the firmware.
$: Alphabet representing the revision of the firmware

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
