Brother HL-2230 User Manual

2-47
Confidential
4.9.3 Main motor failure
4.9.4 Front cover open
Front cover opened
4.9.5 Back cover open
Back cover opened
Step Cause Remedy
1
Flat cable connection failure of the
main motor
Check the flat cable connection of the
main motor, and reconnect it.
2 Main motor failure Replace the main motor.
3
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply
PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
User Check
• Check if the front cover is closed certainly.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB ASSY
(Front cover sensor is mounted in
high voltage power supply PCB
ASSY.)
Check the harness connection of the high
voltage power supply PCB ASSY, and
reconnect it.
2
Part pressing the front cover sensor
is broken, which is provided at
inside of front cover
Replace the front cover ASSY.
3
Front cover sensor failure Check the registration front sensor and
registration rear sensor performance
following the procedure in "Operational
Check of Sensors" (Chapter 5).
If any problem occurs, replace the high
voltage power supply PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
User Check
• Check if the back cover is closed certainly.
• Install the duplex tray certainly.
Step Cause Remedy
1
Harness connection failure of paper
eject sensor PCB ASSY
Check the harness connection of the
paper eject sensor PCB ASSY, and
reconnect it.
2
Part pressing the back cover sensor
is broken, which is provided at
inside of back cover
Replace the back cover ASSY.
3
Part pressing the back cover sensor
is broken, which is provided at
inside of duplex tray
Replace the duplex tray.
4
Back cover sensor failure Replace the paper eject sensor PCB
ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
