4.8.5 Low voltage power supply PCB ASSY failure
4.9 Other Problems
4.9.1 The printer is not turned on, or the LED indication does not appear.
4.9.2 Fuser fan does not rotate.
User Check
• Turn the power off and on.
Step Cause Remedy
1
Harness connection failure of low
voltage power supply PCB ASSY
Check the harness connection of the low
voltage power supply PCB ASSY, and
reconnect it.
2
Low voltage power supply PCB
failure
Replace the low voltage power supply
PCB ASSY. Then, reset the irregular
power supply detection counter following
the procedure described in "3.1 Reset of
Irregular Power Supply Detection
Counter" in Chapter 4.
3 Main PCB failure Replace the main PCB ASSY.
CAUTION :
• The irregular power supply detection error (After blinking the Toner/Drum/Error/Ready
LED, the Toner/Drum/Error LED light up by pressing the [Go] button once. ) occurs
when there is a large distortion in the power supply voltage supplied to the printer.
In this case, if the same power supply is used, the same error may occur even when
the low voltage power supply PCB ASSY is replaced. Ask the user to review the
installation environment.
User Check
• Replace the AC power cord.
Step Cause Remedy
1
Harness connection failure of panel
PCB ASSY
Reconnect the harness of the panel PCB
ASSY correctly.
2 Panel PCB failure Replace the panel PCB ASSY.
3
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply
PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Harness connection failure of the
fuser fan
Reconnect the harness of the fuser fan
correctly.
2 Fuser fan failure Replace the fuser fan.
3
Harness connection failure of high
voltage power supply PCB
Reconnect the harness of the high
voltage power supply PCB ASSY.
4
High voltage power supply PCB
ASSY failure
Replace the high voltage power supply
PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
