Brother HL-2230 User Manual

2-7
Confidential
2.4 Block Diagram
Fig. 2-3
Main PCB ASSY
Registration front/rear sensor PCB
Registration front sensor
Registration rear sensor
Panel PCB ASSY
Error LED
Wireless LAN
PCB ASSY
Drum LED
Toner LED
Ready LED
Go Key
T1 clutch ASSY
REG clutch ASSY
Main motor
Fuser Unit
Center thermistor
Side thermistor
Low voltage power supply PCB
Heater Switch
Paper Edge Sensor PCB
(HL-2250DN/2270DW/
2275DW only)
Paper Edge Sensor
New toner sensor
Polygon motor
Laser unit
Fuser FAN
Back cover/DX
High voltage power supply PCB
Front cover sensor
Paper eject sensor PCB
Paper eject sensor
LD control PCB ASSY
BD sensor

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
