4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N · m (kgf · cm)
Tray cover Taptite bind B M4x12 2 0.8±0.1 (8±1)
Inner chute ASSY Taptite bind B M4x12 2 0.8±0.1 (8±1)
Top cover base
(Top cover ASSY
<except for HL-2130/2135W>)
Taptite bind B M4x12 2 0.8±0.1 (8±1)
SW key holder
(Top cover ASSY <HL-2130/2135W>)
Taptite pan B M3x8 1 0.4±0.1 (4±1)
Fuser unit Taptite pan B M4x14 2 0.8±0.1 (8±1)
LV shield plate cover
Taptite bind B M4x12 3 0.8±0.1 (8±1)
Screw pan (S/P washer)
M3.5x6
10.5±0.05 (5±0.5)
Screw pan (S/P washer)
M3x12DB
10.5±0.1 (5±1)
Low voltage power supply PCB
ASSY
Screw pan (S/P washer)
M3.5x6
10.5±0.05 (5±0.5)
Taptite flat B M3x10 1
0.45 ± 0.05 (4.5 ± 0.5)
Taptite bind B M4x12 1 0.8±0.1 (8±1)
High voltage power supply PCB
ASSY
Taptite bind B M4x12 1 0.8±0.05 (8±0.5)
Laser unit Taptite cup S M3x8 SR 4 0.8±0.05 (8±0.5)
Main PCB ASSY Taptite cup S M3x6 SR 4 0.6±0.1 (6±1)
Front chute ASSY Taptite bind B M4x12 2 0.8±0.1 (8±1)
Under bar Taptite bind B M4x12 1 0.8±0.1 (8±1)
Chute ground plate Taptite bind B M3x10 1
0.55 ± 0.05 (5.5 ± 0.5)
PF frame ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
FG plate laser L Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Main frame L ASSY
Taptite bind B M4x12 2 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)
Develop drive sub ASSY
Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Taptite bind B M4x12 3 0.8±0.1 (8±1)
Motor drive sub ASSY Taptite bind B M4x12 6 0.8±0.1 (8±1)
Main motor Screw bind M3x4 3
0.65 ± 0.05 (6.5 ± 0.5)
Main PCB shield
Taptite cup S M3x6 SR 1 0.6±0.1 (6±1)
Taptite bind B M4x12 2 0.8±0.1 (8±1)

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
