Brother HL-2230 User Manual

2-42
Confidential
4.5 Toner & Drum Problems
4.5.1 If replace toner, cannot delete "Replace Toner".
4.5.2 Cannot detect toner
Identification failure for a new toner cartridge
4.5.3 Toner low
Toner is low
4.5.4 Replace toner
* When the printer is in the stop mode, LEDs indicate REPLACE TONER to guarantee the print
quality. On the other hand, when the continue mode is turned on, the end user can choose
either to continue printing or replace the toner cartridge with a new one.
User Check
• Install a new toner cartridge certainly.
Step Cause Remedy
1
New toner actuator catching on
some position
Correct catching of the new toner
actuator.
2
Harness connection failure of Panel
PCB
Reconnect the harness of the Panel PCB.
3 Panel PCB failure Replace the panel PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Power off or front cover opened
while detecting a new toner
cartridge.
Reset the developing bias voltage and
develop roller counter.
2 New toner actuator loose Re-assemble the new toner actuator
3 New toner sensor failure Replace the panel PCB ASSY.
User Check
• Prepare a new toner cartridge.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
User Check
• Replace the toner cartridge with a new one.
• Press the [Go] button seven times to clear the stop mode*, and shift to the continue
mode.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
