5-5
Confidential
1.4 Detailed Description of Maintenance-mode Functions
■ End user-accessible maintenance mode
1) Test Sample Page
The printer prints a demo page. The printer returns to the ready state after printing.
2) Print Fonts (Network model only)
The printer prints a list of the internal fonts. The printer returns to the ready state after
printing.
3) USB Number Return Value Setting
When the OS used the USB 2.0 FULL in Windows Vista
®
, do not recognize the ID of
USB device depending on a combination of PC and USB device. To avoid this, the return
value of ID can be locked to “0”. It is switched to a set value opposite to a current set
value, whenever switching.
The setting change of return value is distinguished by the LED display when the [Go]
button is released.
The printer returns to the ready state after the setting is completed.
4) Hex Dump Mode
This mode is printed as Hex data. without emulation processing the print data which
received from the PC it is used for defectiveness analysis of the transmitted print data.
LED Setting of return value
Toner LED lights for
one second
Returns the serial number of the printer. (default)
→ Returns “0”.
Drum LED lights for
one second
Returns “0”.
→ Return the serial number of the printer.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
