2-21
Confidential
4. ERROR SYMPTOM/ERROR CAUSE AND REMEDY
4.1 Paper Feeding Problems
Problems related to paper feeding are end user recoverable if following the User Check
items. If the same problem occurs again, follow each procedure in the order of the number
described in the Step column in the tables below.
4.1.1 Pickup function of Paper tray does not work.
4.1.2 No feeding
Not detect paper at feeding input
Step Cause Remedy
1
Link arm catching on some position Re-assemble the link arm.
2
Pick-up roller holder ASSY
catching on some position
Re-assemble the pick-up roller holder
ASSY.
3
Harness connection failure of main
motor
Reconnect the harness of the main motor.
4
Plate-up gear (gear Z19M10 or lift
gear 46) failure
Replace the plate-up gear (gear Z19M10
or lift gear 46).
5 Main motor failure Replace the main motor.
6
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply PCB
ASSY.
7 Main PCB failure Replace the main PCB ASSY.
User Check
• Check if the paper tray is loaded correctly.
• Check if the paper is loaded into the paper tray correctly. Then press the [Go] button.
• Check that the paper smaller than the specified size is not loaded.
• Adjust the paper guide corresponding to the position of paper guide.
• Check if too much paper is loaded in the tray.
• Clean the surface of the separation pad or pick-up roller.
Step Cause Remedy
1
Lift arm and pick-up roller holder
ASSY not assembled correctly
Re-assemble the lift arm and pick-up roller
holder ASSY.
2
Harness connection failure of T1
clutch ASSY
Check the harness connections of the T1
clutch ASSY, and reconnect it.
3
Harness connection failure of
paper edge sensor harness ASSY
(HL-2250DN/2270DW/2275DW only)
Check the harness connections of the
paper edge sensor harness ASSY, and
reconnect it.
4 Paper feeding roller failure Replace the paper feeding kit.
5
Plate-up gear (gear Z19M10 or lift
gear 46) failure
Replace the plate-up gear (gear Z19M10
or lift gear 46).
6 T1 clutch ASSY failure Replace the T1 clutch ASSY.
7 Panel PCB failure Replace the panel PCB ASSY.
8 Main PCB failure Replace the main PCB ASSY.
9
Paper edge sensor failure
(HL-2250DN/2270DW/2275DW only)
Check the sensor performance following
the procedure in "Operational Check of
Sensors" (Chapter 5). If any problem
occurs, replace the PF frame ASSY.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
