Brother HL-2230 User Manual

2-44
Confidential
4.6 Fuser Unit Problems
4.6.1 Fuser Unit failure
4.7 Laser Unit Problems
4.7.1 Laser Unit failure
Step Cause Remedy
1
Harness connection failure between
fuser unit connector and paper eject
sensor PCB ASSY
Check the harness connection between
fuser unit connector and paper eject
sensor PCB ASSY, and reconnect it.
2
Harness connection failure between
fuser unit connector and low voltage
power supply PCB ASSY
Check the harness connection between
fuser unit connector and low voltage power
supply PCB ASSY, and reconnect it.
3
Harness connection failure between
paper eject sensor PCB ASSY and
main PCB.
Check the harness connection between
paper eject sensor PCB ASSY and main
PCB, and reconnect it.
4
Paper eject sensor PCB ASSY
failure
Replace the paper eject sensor PCB
ASSY.
5
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply
PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.
7 Fuser unit failure Replace the fuser unit.
CAUTION :
• Turn off the power switch once, and after checking that the fuser unit sufficiently cools
down, turn on the power switch again and leave the printer for ten minutes. Then, this
problem may be cleared.
Turn the power on while pressing the [Go] button, when the front cover is open. After
Toner, Drum and Error LEDs light up, release the [Go] button. Check that all LEDs go
off, press the [Go] button once, and after all LEDs light up again, press the [Go] button
once again. Then, this problem may be cleared. However, be careful because the fuser
unit melts if the fuser unit does not sufficiently cool down.
User Check
• There is a possibility that the condensation has occurred. Turn off the power, and leave
the machine at least one hour in a well-ventilated place. And then turn on the power.
Step Cause Remedy
1
Harness connection failure of laser
unit
Check the harness connection of the
laser unit, and reconnect them.
2 Main PCB failure Replace the main PCB ASSY.
3 Laser unit failure Replace the laser unit.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
