Brother HL-2230 User Manual

2-22
Confidential
4.1.3 No paper fed manual feed slot
Not detect paper at feeding from manual feed slot
4.1.4 Double feeding
User Check
• Load the paper into the manual feed slot.
Step Cause Remedy
1
Harness connection failure of
registration front/rear sensor PCB
ASSY
Check the harness connection of the
registration front/rear sensor PCB ASSY,
and reconnect it.
2
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply PCB
ASSY.
3 Main PCB failure Replace the main PCB ASSY.
4
Registration front/rear sensor
failure
Check the sensor performance following
the procedure in "Operational Check of
Sensors" (Chapter 5).
If any problem occurs, replace the regist
frame ASSY.
User Check
• Check if the paper is loaded into the paper tray correctly.
• Check if the thickness of the paper is 60 to 105 g/m
2
.
• Clean the separation pad.
• Check that too much paper is not loaded in each tray.
Step Cause Remedy
1 Paper feeding roller failure Replace the paper feeding kit.

Brother HL-2230 Specifications

General

Network ready	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Custom media width	76.2 - 220 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Windows operating systems supported	Yes
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	65 W
Package weight	8000 g
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Server 2003, Server 2003 x64 Edition, Vista, Server 2008, Server 2008 R2, Windows 7 Mac OS X 10.4.11, 10.5.x, 10.6.x
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Interactive Help

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
