12 - 2
PRINTER DRIVER SETTINGS (FOR WINDOWS
®
ONLY)
BHL-FB-MFC-5100C-FM5.5
Paper Tab
The paper tab screen allows you to set up the Paper Size, Paper Source, Paper
Thickness, Orientation, Scaling, and Copy/Page Order.
To access the Brother printer driver, select Print from the File menu. In the Print dialog
box, select Brother MFC-5100C from the Name drop down list. Click the Properties
button. The Brother MFC-5100C on BRMFC: Properties dialog box will appear:
Select the Apply button to apply your selected settings.
To return to the default settings, click the Default button, then click the Apply
button.
1
Select the Paper Size and Orientation.
2
Select number of Copies and Page Order.
3
Select Paper Thickness, Scaling and Paper Source.
Paper Size
The paper size selection provides a large selection of standard paper sizes or you
can even create custom sizes ranging form 3.5 × 5” to 8.5 × 14”. To select the
paper size you want to use click the icon.
1
2
3
To Next Page
