Views of Projector Parts
Front-right View
12
10 11 12
3
45 678
9
Item Label Description
1 Filter Cover The internal fan pulls cool air to the projector via the intake.
2 Front IR Receiver Receives IR signal from remote control.
3 Color Wheel Cover Slide to change the color wheel.
4 Lens Release Button Push to change the projector lens.
5 Lens Projection lens. (Optional)
6 LED Indicators Shows the status of the projector.
7 Filter Clean lter every 500 hours to prolong the life of the projector.
8 Filter Cover The internal fan pulls cool air to the projector via the intake.
9 Adjusting Foots Adjust the levelness the projection angle.
10 I/O Panel Use to connect to other devices.
11 Kensington Lock Secure to permanent object with a Kensington
®
Lock system.
12 Control Panel Use buttons to select or adjust the settings of the projector.
