Canon LX-MU700 User Manual

72
Screen Size LX-IL05LZ LX-IL06UL
Long zoom lens Ultra long zoom lens
Diagonal Width Height (A) Distance (B)
Wide Tele Wide Tele
(inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m)
40 1.02 34 0.86 21 0.54 118.7 3.01 181 4.6 173.9 4.42 277.7 7.05
50 1.27 42 1.08 26 0.67 149.7 3.8 227.6 5.78 220.2 5.59 350 8.89
60 1.52 51 1.29 32 0.81 180.7 4.59 274.1 6.96 266.6 6.77 422.3 10.73
80 2.03 68 1.72 42 1.08 242.7 6.16 367.3 9.33 359.4 9.13 567 14.4
100 2.54 85 2.15 53 1.35 304.3 7.73 460.4 11.7 452.1 11.48 711.6 18.07
120 3.05 102 2.58 64 1.62 366.7 9.31 553.6 14.06 544.9 13.84 856.2 21.75
150 3.81 127 3.23 79 2.02 459.4 11.67 693.3 17.61 684 17.37 1073.1 27.26
180 4.57 153 3.88 95 2.42 552.4 14.03 833 21.16 823.1 20.91 1290.1 32.77
200 5.08 170 4.31 106 2.69 614.7 15.6 926.4 23.53 915.9 23.26 1434.7 36.44
300 7.62 254 6.46 159 4.04 924 23.47 1392.1 35.36 1379.6 35.04 2157.8 54.81
400 10.16 339 8.62 212 5.38 1233.9 31.34 1857.9 47.19 1843.3 46.82 2880.9 73.18
500 12.7 424 10.77 265 6.73 1543.7 39.21 2323.6 59.02 2307.1 58.6 3604 91.54
Screen Size LX-IL07WF
Short xed
lens
Diagonal Width Height (A) Distance (B)
N/A
(inch) (m) (inch) (m) (inch) (m) (inch) (m)
40 1.02 34 0.86 21 0.54 25.1 0.64
50 1.27 42 1.08 26 0.67 31.8 0.81
60 1.52 51 1.29 32 0.81 38.5 0.98
80 2.03 68 1.72 42 1.08 52 1.32
100 2.54 85 2.15 53 1.35 65.5 1.66
120 3.05 102 2.58 64 1.62 78.9 2.01
150 3.81 127 3.23 79 2.02 99.1 2.52
180 4.57 153 3.88 95 2.42 119.3 3.03
200 5.08 170 4.31 106 2.69 132.8 3.37
300 7.62 254 6.46 159 4.04 200.1 5.08
400 10.16 339 8.62 212 5.38 267.4 6.79
500 12.7 424 10.77 265 6.73 334.8 8.5
** The table indicates projection range, optical performance is only guaranteed from 50 to 300 inches.
Lens Series
Part
Number
Lens Name F Number Focal Length Zoom
Ratio
Screen
Size
Throw Ratio
Lens Shift Range
WUXGA
V H
LX-IL01UW Ultra wide zoom lens 1.96-2.3 11.3-14.1mm 1.25:1 40”-500” 0.75-0.93:1
0~50% +/-6.7%
LX-IL02WZ Wide zoom lens 1.85-2.5 18.7-26.5mm 1.41:1 40”-500” 1.25-1.79:1
0~50% +/-10%
LX-IL03ST Standard zoom lens 1.7-1.9 26-34mm 1.3:1 40”-500” 1.73-2.27:1
0~50% +/-10%
LX-IL04MZ Middle zoom lens 1.86-2.48 32.9-54.2mm 1.65:1 40”-500” 2.22-3.67:1
0~50% +/-10%
LX-IL05LZ Long zoom lens 1.85-2.41 52.8-79.1mm 1.5:1 40”-500” 3.58-5.38-1
0~50% +/-10%
LX-IL06UL Ultra long zoom lens 1.85-2.48 78.5-121.9mm 1.55:1 40”-500” 5.31-8.26:1
0~50% +/-10%
LX-IL07WF Short xed lens 1.85 11.6mm - 40”-500” 0.76:1
0% 0%
** The table indicates projection range, optical performance is only guaranteed from 50 to 300 inches.
