62
Replacing the Filter on the Left Side
1.
Flip the lter cover following the direction.
2.
Remove the lter cover
.
3.
Remove the lter from the front side of the projector
.
4.
Install the lter
.
5.
Align the pins on the lter cover with the projector
.
6.
Flip to install the lter cover
.
