69
Specications
Product Specications
Model name LX-MU700
Display system 1-CHIP DLP™
Display device
Type DMD
Size / Aspect ratio 0.67”x1 / 16:10
Drive system DLP™ x 1 chip
Number dots / Total number
dots
2,304,000 (1920 x 1200) x 1 / 2,304,000
Projection
lens (*1)
Zoom ratio / Focal length /
F value
1.3x / f = 26 to 34mm / F = 1.64 to 1.86
Zooming / Focusing system Electric / Electric
Lens shift V:0% to +50% , H: ±10% Electric
Light source Super-high pressure mercury lamp 350W x 2
Image size (projection distance) (*1) 50” to 300” (1.83m to 14.9m / 6’ to 49’ )
Number of colors 1.07 billion colors
Brightness (*1) (*2) (*3) 7500 lumen (in presentation mode)
Contrast ratio (*1) (*2) (*3) 2100:1 (Fully white: fully black, Dynamic Black on, in
presentation mode)
Display scanning frequency H: 15 to108 kHz , V: 48-120 Hz
Maximum input resolution 1920 x 1200 dots
Image signal
Digital PC WUXGA (RB) / WSXGA+ / UXGA / SXGA+ / WXGA+ / WXGA /
SXGA / XGA / SVGA / VGA
Analog PC WUXGA (RB) / WSXGA+ / UXGA / SXGA+ / WXGA+ / WXGA /
SXGA / XGA / SVGA / VGA
Digital video 1080p / 1080i / 720p / 576p / 480p
Component video 1080p / 1080i / 720p / 576p / 480p / 576i / 480i
HDBaseT Same as the Digital PC and Digital video
Terminals
HDMI Digital PC / Digital video
DVI-D Digital PC / Digital video
DisplayPort Digital PC / Digital video
RJ45 HDBaseT / Network
5BNC Analog PC / Component video
Dsub15 Analog PC
Dsub15 (output) Analog PC
Dsub9 RS-232 (serial communication)
USB type B Connect to an PC for maintenance
Mini pin jack Connect to a wired remote
Mini pin jack 12 V output (trigger for screen operation)
3D sync out 3D IR synchronization output
Noise 36dB/41dB (Dual-lamp Eco/Dual-lamp Normal)
Operating temperature 5°C (41°F) to 40°C (104°F)
Power supply AC 100-240V, 50/60Hz
Maximum power consumption 850W
Standby mode power consumption ECO Standby: <0.5W (No RJ-45, No RS-232)
Networking standby: <6W with RJ-45
To Next Page
