37
Preparing the Camcorder
English
Using a Tripod
You can mount the camcorder on any tripod with a 1/4" mounting screw, no longer than
5.5 mm (0.2 in.). Using tripods with longer mounting screws may cause damage to the
camcorder.
Using a Tripod with 3/8" Mounting Screws
To use a tripod with 3/8" mounting screws, first attach the optional TB-1 Tripod Adapter Base to the camcorder
and then attach the tripod to the adapter base.
1 Remove the tripod base from the camcorder.
• Remove the 4 screws and then remove the base.
2 Attach the optional TB-1 Tripod Adapter Base.
• Firmly screw in the 4 screws.
3 Attach the tripod.
• Firmly screw in the tripod screw.
• If a tripod has both a 1/4" screw and a 3/8" mounting screw, firmly screw in both.
5.5 mm
