Synchronizing with an External Device
96
Reference Video Signal Output
After changing the GENLOCK/SYNC OUT terminal’s function to [SYNC Output], you can output the camcorder’s
video signal as a reference sync signal (HD tri-level signal) to synchronize an external device to this camcorder.
The reference video signal output will have the same frequency as the signal output from the 3G/HD-SDI
terminal.
1 Open the [GENLOCK/SYNC OUT] submenu.
[¢ Video Setup] > [GENLOCK/SYNC OUT]
2 Select [SYNC Output] and then press SET.
• If necessary, change the scan mode (P or PsF) with the [¢ Video
Setup] > [SYNC Scan Mode] setting.
• If necessary to synchronize with older XF camcorders, you can
change the reference output signal with the [¤ TC/UB Setup] >
[Time Code] > [XF Legacy Sync] setting.
Synchronization signals
1
[¤ TC/UB Setup] > [Time Code] > [XF Legacy Sync].
2
You can select P or PsF output with the [¢ Video Setup] > [SYNC Scan Mode] setting.
Time Code Signal Output
The time code will be output from the TIME CODE terminal as an SMPTE-standard LTC timing signal. The user
bit will also be output. Before connecting the device, set [¤ TC/UB Setup] > [Time Code] > [TC In/Out] to
[Out] to change the TIME CODE terminal to output (A 95).
The embedded time code will be output also from the 3G/HD-SDI terminal and the MON. terminal. Additionally,
you can set [¢ Video setup] > [HDMI Time Code] to [On], to output the embedded time code also from the
HDMI OUT terminal.
NOTES
• The camcorder will output a time code that has the same frequency as that used for recording. When the
frame rate is set to 23.98P, you can output instead a 30-frame time code signal by setting [¤ TC/UB
Setup] > [Time Code] > [XF Legacy Sync] to [On].
Operating modes:
Video output from the 3G/HD-SDI terminal
Signal output from the GENLOCK/SYNC OUT terminal
mode
mode
Resolution Frame rate
[XF Legacy Sync]
1
set to
[Off]
[XF Legacy Sync]
1
set to
[On]
1920x1080
59.94i / 59.94P 1080/59.94i
1080/59.94i 1080/59.94i29.97 (P/PsF) 1080/29.97 (P/PsF)
2
23.98P 1080/23.98 (P/PsF)
2
1280x720
59.94P 720/59.94P
720/59.94P 720/59.94P29.97P 720/29.97P
23.98P 720/23.98P
Operating modes:
[¢ Video Setup]
[GENLOCK/SYNC OUT]
[Genlock]
