Gain
62
Gain
Depending on the shooting conditions you may want to adjust the brightness of the image. You can do so by
changing the gain value to adjust the sensitivity of the sensor. The camcorder offers 3 independently adjustable
gain levels (L/M/H), for each of which you can select automatic gain (including the option to limit the maximum
gain value) or manual gain control.
Available gain settings
* These values cannot be selected when the [Gamma] setting in the custom picture file (A 135) is set to [Wide DR].
Selecting the Gain Level
You can set beforehand 3 gain levels (including automatic gain control) and then select quickly which one to
apply simply by changing the position of the GAIN switch.
Set the GAIN switch to the position you want to adjust
(L, M or H).
• L, M or H and the gain value currently assigned to that
position will be displayed on the screen.
Automatic Gain Control (AGC)
Using the Joystick
1 Press SET and push the joystick left/right until the
gain mode icon is highlighted in orange.
2 Push the joystick up/down to select the icon and
then press SET.
• The current position of the GAIN switch will be set to automatic gain control.
NOTES
• You can also set the respective [Mode] setting ([~ Camera Setup] > [Gain] > [L], [M] or [H] > [Mode]) to
[Automatic]. Additionally, if you set an assignable button to [Gain Mode] (A 129), you can press the button to
change the gain mode of the currently selected gain position between manual and automatic.
Remote Operation Using Browser Remote
After completing the necessary preparations (A 182), you can change the gain mode of the currently selected
gain position remotely from a connected device using the Browser Remote application.
1 Press the gain mode button on the Browser Remote screen.
2 Select [Auto].
Operating modes:
Increment Gain
3 dB -6 dB*, -3 dB*, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB, 21 dB, 24 dB, 27 dB, 33 dB*
0.5 dB (when [Fine Tuning] is selected) -6 dB to -0.5 dB*, 0 dB to 27 dB
