DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
(Optional) Specifies the CA trustpoint to be used if the remote HTTP
server requests client authentication. Using this command assumes
ip http client secure-trustpoint name
Example:
Switch(config)# ip http client
Step 2
that you have already configured a CA trustpoint by using the
previous procedure. The command is optional if client authentication
is not needed or if a primary trustpoint has been configured.
secure-trustpoint your_trustpoint
(Optional) Specifies the CipherSuites (encryption algorithms) to be
used for encryption over the HTTPS connection. If you do not have
ip http client secure-ciphersuite
{[3des-ede-cbc-sha] [rc4-128-md5]
[rc4-128-sha] [des-cbc-sha]}
Step 3
a reason to specify a particular CipherSuite, you should allow the
server and client to negotiate a CipherSuite that they both support.
This is the default.
Example:
Switch(config)# ip http client
secure-ciphersuite rc4-128-md5
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 4
Monitoring Secure HTTP Server and Client Status
To monitor the SSL secure server and client status, use the privileged EXEC commands in the following table.
Table 16: Commands for Displaying the SSL Secure Server and Client Status
PurposeCommand
Shows the HTTP secure client configuration.show ip http client secure status
Shows the HTTP secure server configuration.show ip http server secure status
Shows the generated self-signed certificate for secure
HTTP connections.
show running-config
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 135
Configuring Secure Socket Layer HTTP
Monitoring Secure HTTP Server and Client Status

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
