IP Source Guard Configuration Guidelines
•
You can configure static IP bindings only on nonrouted ports. If you enter the ip source binding
mac-address vlan vlan-id ip-address interface interface-id global configuration command on a routed
interface, this error message appears:
Static IP source binding can only be configured on switch port.
•
When IP source guard with source IP filtering is enabled on an interface, DHCP snooping must be
enabled on the access VLAN for that interface.
•
If you are enabling IP source guard on a trunk interface with multiple VLANs and DHCP snooping is
enabled on all the VLANs, the source IP address filter is applied on all the VLANs.
If IP source guard is enabled and you enable or disable DHCP snooping on a VLAN on
the trunk interface, the switch might not properly filter traffic.
Note
•
You can enable this feature when 802.1x port-based authentication is enabled.
•
When you configure IP source guard smart logging, packets with a source address other than the specified
address or an address learned by DHCP are denied, and the packet contents are sent to a NetFlow
collector. If you configure this feature, make sure that smart logging is globally enabled.
•
In a switch stack, if IP source guard is configured on a stack member interface and you remove the the
configuration of that switch by entering the no switch stack-member-number provision global
configuration command, the interface static bindings are removed from the binding table, but they are
not removed from the running configuration. If you again provision the switch by entering the switch
stack-member-number provision command, the binding is restored.
To remove the binding from the running configuration, you must disable IP source guard before entering
the no switch provision command. The configuration is also removed if the switch reloads while the
interface is removed from the binding table.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 237
Configuring IP Source Guard
IP Source Guard Configuration Guidelines

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
