802.1x Multiple Authentication Mode
Multiple-authentication (multiauth) mode allows multiple authenticated clients on the data VLAN. Each host
is individually authenticated. If a voice VLAN is configured, this mode also allows one client on the VLAN.
(If the port detects any additional voice clients, they are discarded from the port, but no violation errors occur.)
If a hub or access point is connected to an 802.1x-enabled port, each connected client must be authenticated.
For non-802.1x devices, you can use MAC authentication bypass or web authentication as the per-host
authentication fallback method to authenticate different hosts with different methods on a single port.
There is no limit to the number of data hosts can authenticate on a multiauthport. However, only one voice
device is allowed if the voice VLAN is configured. Since there is no host limit defined violation will not be
trigger, if a second voice is seen we silently discard it but do not trigger violation. For MDA functionality on
the voice VLAN, multiple-authentication mode assigns authenticated devices to either a data or a voice VLAN,
depending on the VSAs received from the authentication server.
When a port is in multiple-authentication mode, the guest VLAN and the authentication-failed VLAN
features do not activate.
Note
You can assign a RADIUS-server-supplied VLAN in multi-auth mode, under the following conditions:
•
The host is the first host authorized on the port, and the RADIUS server supplies VLAN information
•
Subsequent hosts are authorized with a VLAN that matches the operational VLAN.
•
A host is authorized on the port with no VLAN assignment, and subsequent hosts either have no VLAN
assignment, or their VLAN information matches the operational VLAN.
•
The first host authorized on the port has a group VLAN assignment, and subsequent hosts either have
no VLAN assignment, or their group VLAN matches the group VLAN on the port. Subsequent hosts
must use the same VLAN from the VLAN group as the first host. If a VLAN list is used, all hosts are
subject to the conditions specified in the VLAN list.
•
Only one voice VLAN assignment is supported on a multi-auth port.
•
After a VLAN is assigned to a host on the port, subsequent hosts must have matching VLAN information
or be denied access to the port.
•
You cannot configure a guest VLAN or an auth-fail VLAN in multi-auth mode.
•
The behavior of the critical-auth VLAN is not changed for multi-auth mode. When a host tries to
authenticate and the server is not reachable, all authorized hosts are reinitialized in the configured VLAN.
Multi-auth Per User VLAN assignment
This feature is supported only on Catalyst 2960X switches running the LAN base imageNote
The Multi-auth Per User VLAN assignment feature allows you to create multiple operational access VLANs
based on VLANs assigned to the clients on the port that has a single configured access VLAN. The port
configured as an access port where the traffic for all the VLANs associated with data domain is not dot1q
tagged, and these VLANs are treated as native VLANs.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 273
Configuring IEEE 802.1x Port-Based Authentication
802.1x Multiple Authentication Mode

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
