Cisco Catalyst 2960-X User Manual

PurposeCommand or Action
Specifies the format of the MAC address in the User-Name attribute of
MAB-generated Access-Request packets.
mab request format attribute 1 groupsize
{1 | 2 | 4 |12} [separator {- | : | .}
{lowercase | uppercase}]
Step 2
1—Sets the username format of the 12 hex digits of the MAC address.
Example:
Switch(config)# mab request format
group size—The number of hex nibbles to concatenate before insertion of a
separator. A valid groupsize must be either 1, 2, 4, or 12.
separator—The character that separates the hex nibbles according to group
size. A valid separator must be either a hyphen, colon, or period. No separator
is used for a group size of 12.
attribute 1 groupsize 12
{lowercase | uppercase}—Specifies if nonnumeric hex nibbles should be in
lowercase or uppercase.
2—Specifies a custom (nondefault) value for the User-Password attribute in
MAB-generated Access-Request packets.
mab request format attribute2 {0 | 7} text
Example:
Switch(config)# mab request format
Step 3
0—Specifies a cleartext password to follow.
7—Specifies an encrypted password to follow.
attribute 2 7 A02f44E18B12
text—Specifies the password to be used in the User-Password attribute.
When you send configuration information in e-mail, remove type 7
password information. The show tech-support command removes
this information from its output by default.
Note
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 4
Configuring 802.1x User Distribution
Beginning in privileged EXEC mode, follow these steps to configure a VLAN group and to map a VLAN to
it:
SUMMARY STEPS
1.
configure terminal
2.
vlan group vlan-group-name vlan-list vlan-list
3.
end
4.
no vlan group vlan-group-name vlan-list vlan-list
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 335
Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x User Distribution

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
