PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Configures protocol storm protection for ARP, IGMP, or DHCP.
psp {arp | dhcp | igmp} pps value
Step 3
Example:
Switch(config)# psp dhcp pps 35
For value, specifies the threshold value for the number of packets per
second. If the traffic exceeds this value, protocol storm protection is
enforced. The range is from 5 to 50 packets per second.
(Optional) Enables error-disable detection for protocol storm
protection. If this feature is enabled, the virtual port is error disabled.
errdisable detect cause psp
Example:
Switch(config)# errdisable detect cause
Step 4
If this feature is disabled, the port drops excess packets without error
disabling the port.
psp
(Optional) Configures an auto-recovery time (in seconds) for
error-disabled virtual ports. When a virtual port is error-disabled, the
errdisable recovery interval time
Example:
Switch
Step 5
switch auto-recovers after this time. The range is from 30 to 86400
seconds.
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 6
Verifies your entries.show psp config {arp | dhcp | igmp}
Example:
Switch# show psp config dhcp
Step 7
Monitoring Protocol Storm Protection
PurposeCommand
Verify your entries.show psp config {arp | dhcp | igmp}
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
436 OL-29048-01
Configuring Port-Based Traffic Control
Monitoring Protocol Storm Protection

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
