Table 25: Authentication Manager Commands and Earlier 802.1x Commands
DescriptionThe equivalent 802.1x
commands in Cisco IOS
Release 12.2(46)SE and earlier
The authentication manager
commands in Cisco IOS
Release 12.2(50)SE or later
Enable 802.1x authentication with the
wake-on-LAN (WoL) feature, and configure
the port control as unidirectional or
bidirectional.
dot1x control-direction
{both | in}
authentication
control-direction {both | in}
Enable the restricted VLAN on a port.
Enable the
inaccessible-authentication-bypass feature.
Specify an active VLAN as an 802.1x guest
VLAN.
dot1x auth-fail vlan
dot1x critical (interface
configuration)
dot1x guest-vlan6
authentication event
Configure a port to use web authentication
as a fallback method for clients that do not
support 802.1x authentication.
dot1x fallback
fallback-profile
authentication fallback
fallback-profile
Allow a single host (client) or multiple hosts
on an 802.1x-authorized port.
dot1x host-mode {single-host
| multi-host | multi-domain}
authentication host-mode
[multi-auth | multi-domain |
multi-host | single-host]
Provides the flexibility to define the order
of authentication methods to be used.
mabauthentication order
Enable periodic re-authentication of the
client.
dot1x reauthenticationauthentication periodic
Enable manual control of the authorization
state of the port.
dot1x port-control {auto |
force-authorized |
force-unauthorized}
authentication port-control
{auto | force-authorized |
force-un authorized}
Set the 802.1x timers.dot1x timeoutauthentication timer
Configure the violation modes that occur
when a new device connects to a port or
when a new device connects to a port after
the maximum number of devices are
connected to that port.
dot1x violation-mode
{shutdown | restrict |
protect}
authentication violation
{protect | restrict | shutdown}
Ports in Authorized and Unauthorized States
During 802.1x authentication, depending on the switch port state, the switch can grant a client access to the
network. The port starts in the unauthorized state. While in this state, the port that is not configured as a voice
VLAN port disallows all ingress and egress traffic except for 802.1x authentication, CDP, and STP packets.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
270 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Ports in Authorized and Unauthorized States

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
