The number of hosts per multi-auth port is 8, however there can be more hosts.
The Multi-auth Per User VLAN assignment feature is not supported for Voice domain. All clients in Voice
domain on a port must use the same VLAN.
Note
The following scenarios are associated with the multi-auth Per User VLAN assignments:
Scenario one
When a hub is connected to an access port, and the port is configured with an access VLAN (V0).
The host (H1) is assigned to VLAN (V1) through the hub. The operational VLAN of the port is changed to
V1. This behaviour is similar on a single-host or multi-domain-auth port.
When a second host (H2) is connected and gets assigned to VLAN ( V2), the port will have two operational
VLANs (V1 and V2). If H1 and H2 sends untagged ingress traffic, H1 traffic is mapped to VLAN (V1) and
H2 traffic to VLAN (V2), all egress traffic going out of the port on VLAN (V1) and VLAN (V2) are untagged.
If both the hosts, H1 and H2 are logged out or the sessions are removed due to some reason then VLAN (V1)
and VLAN (V2) are removed from the port, and the configured VLAN (V0) is restored on the port.
Scenario two
When a hub is connected to an access port, and the port is configured with an access VLAN (V0). The host
(H1) is assigned to VLAN (V1) through the hub. The operational VLAN of the port is changed to V1.
When a second host (H2) is connected and gets authorized without explicit vlan policy, H2 is expected to use
the configured VLAN (V0) that is restored on the port. A ll egress traffic going out of two operational VLANs,
VLAN (V0) and VLAN (V1) are untagged.
If host (H2 ) is logged out or the session is removed due to some reason then the configured VLAN (V0) is
removed from the port, and VLAN (V1) becomes the only operational VLAN on the port.
Scenario three
When a hub is connected to an access port in open mode, and the port is configured with an access VLAN
(V0) .
The host (H1) is assigned to VLAN (V1) through the hub. The operational VLAN of the port is changed to
V1. When a second host (H2) is connected and remains unauthorized, it still has access to operational VLAN
(V1) due to open mode.
If host H1 is logged out or the session is removed due to some reason, VLAN (V1) is removed from the port
and host (H2) gets assigned to VLAN (V0).
The combination of Open mode and VLAN assignment has an adverse affect on host (H2) because it has
an IP address in the subnet that corresponds to VLAN (V1).
Note
Limitation in Multi-auth Per User VLAN assignment
In the Multi-auth Per User VLAN assignment feature, egress traffic from multiple vlans are untagged on a
port where the hosts receive traffic that is not meant for them. This can be a problem with broadcast and
multicast traffic.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
274 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
802.1x Multiple Authentication Mode

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
