PurposeCommand or Action
Defines the VLAN membership mode for the port.switchport mode access
Example:
Switch(config-if)# switchport mode access
Step 8
Assigns the ports to the same VLAN as configured in Step 2.
switchport access vlan vlan-id
Example:
Switch(config-if)# switchport access vlan 1
Step 9
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 10
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 11
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 12
Prerequisites for Configuring DHCP Snooping and Option 82
The prerequisites for DHCP Snooping and Option 82 are as follows:
•
You must globally enable DHCP snooping on the switch.
•
Before globally enabling DHCP snooping on the switch, make sure that the devices acting as the DHCP
server and the DHCP relay agent are configured and enabled.
•
If you want the switch to respond to DHCP requests, it must be configured as a DHCP server.
•
Before configuring the DHCP snooping information option on your switch, be sure to configure the
device that is acting as the DHCP server. You must specify the IP addresses that the DHCP server can
assign or exclude, or you must configure DHCP options for these devices.
•
For DHCP snooping to function properly, all DHCP servers must be connected to the switch through
trusted interfaces. In a service-provider network, a trusted interface is connected to a port on a device
in the same network.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 221
Configuring DHCP
Prerequisites for Configuring DHCP Snooping and Option 82

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
