Configuring VLAN ID-based MAC Authentication
Beginning in privileged EXEC mode, follow these steps:
SUMMARY STEPS
1.
configure terminal
2.
mab request format attribute 32 vlan access-vlan
3.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Enables VLAN ID-based MAC authentication.mab request format attribute 32 vlan access-vlan
Example:
Switch(config)# mab request format attribute 32 vlan
Step 2
access-vlan
(Optional) Saves your entries in the
configuration file.
copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 3
Configuring Flexible Authentication Ordering
The examples used in the instructions below changes the order of Flexible Authentication Ordering so that
MAB is attempted before IEEE 802.1X authentication (dot1x). MAB is configured as the first authentication
method, so MAB will have priority over all other authentication methods.
Before changing the default order and priority of these authentication methods, however, you should
understand the potential consequences of those changes. See http://www.cisco.com/en/US/prod/collateral/
iosswrel/ps6537/ps6586/ps6638/application_note_c27-573287_ps6638_Products_White_Paper.html for
details.
Note
Beginning in privileged EXEC mode, follow these steps:
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
350 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring VLAN ID-based MAC Authentication

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
