PurposeCommand or Action
Configures the VLAN for this port.
switchport access vlan vlan-id
Example:
Switch(config-if)# switchport access vlan
Step 6
10
Enables IP source guard with source IP address filtering.ip verify source[tracking] [mac-check ]
Step 7
Example:
Switch(config-if)# ip verify source tracking
mac-check
(Optional) tracking—Enables IP source guard for static hosts.
(Optional) mac-check—Enables MAC address filtering.
The command ip verify source tracking mac-checkenables IP
source guard for static hosts with MAC address filtering.
Establishes a maximum limit for the number of static IPs that
the IP device tracking table allows on the port. The range is 1to
10. The maximum number is 10.
ip device tracking maximum number
Example:
Switch(config-if)# ip device tracking
Step 8
You must configure the ip device tracking maximum
limit-number interface configuration command.
Note
maximum 8
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 9
Monitoring IP Source Guard
Table 22: Privileged EXEC show Commands
PurposeCommand
Displays the IP source guard configuration on the
switch or on a specific interface.
show ip verify source [ interface interface-id ]
Displays information about the entries in the IP device
tracking table.
show ip device tracking { all | interface interface-id
| ip ip-address | mac imac-address}
Table 23: Interface Configuration Commands
PurposeCommand
Verifies the data source.ip verify source tracking
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 241
Configuring IP Source Guard
Monitoring IP Source Guard

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
