Authentication Process
When you enable web-based authentication, these events occur:
•
The user initiates an HTTP session.
•
The HTTP traffic is intercepted, and authorization is initiated. The switch sends the login page to the
user. The user enters a username and password, and the switch sends the entries to the authentication
server.
• If the authentication succeeds, the switch downloads and activates the user’s access policy from the
authentication server. The login success page is sent to the user.
•
If the authentication fails, the switch sends the login fail page. The user retries the login. If the maximum
number of attempts fails, the switch sends the login expired page, and the host is placed in a watch list.
After the watch list times out, the user can retry the authentication process.
•
If the authentication server does not respond to the switch, and if an AAA fail policy is configured, the
switch applies the failure access policy to the host. The login success page is sent to the user.
•
The switch reauthenticates a client when the host does not respond to an ARP probe on a Layer 2 interface,
or when the host does not send any traffic within the idle timeout on a Layer 3 interface.
•
The feature applies the downloaded timeout or the locally configured session timeout.
Beginning with Cisco IOS XE Denali 16.1.1 and later, the default session timeout value
for web-based authentication on WLC is 1800 seconds. The default session timeout
value was infinite seconds, prior to Cisco IOS XE Denali 16.1.1.
Note
•
If the terminate action is RADIUS, the feature sends a nonresponsive host (NRH) request to the server.
The terminate action is included in the response from the server.
•
If the terminate action is default, the session is dismantled, and the applied policy is removed.
Local Web Authentication Banner
With Web Authentication, you can create a default and customized web-browser banners that appears when
you log in to a switch.
The banner appears on both the login page and the authentication-result pop-up pages. The default banner
messages are as follows:
•
Authentication Successful
•
Authentication Failed
•
Authentication Expired
The Local Web Authentication Banner can be configured in legacy and new-style (Session-aware) CLIs as
follows:
• Legacy mode—Use the ip admission auth-proxy-banner http global configuration command.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
362 OL-29048-01
Configuring Web-Based Authentication
Authentication Process

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
