TACACS is not supported with 802.1x authentication.Note
Until the client is authenticated, 802.1x access control allows only Extensible Authentication Protocol over
LAN (EAPOL), Cisco Discovery Protocol (CDP), and Spanning Tree Protocol (STP) traffic through the port
to which the client is connected. After authentication is successful, normal traffic can pass through the port.
For complete syntax and usage information for the commands used in this chapter, see the “RADIUS
Commands” section in the Cisco IOS Security Command Reference, Release 3SE
Note
Port-Based Authentication Process
To configure IEEE 802.1X port-based authentication, you must enable authentication, authorization, and
accounting (AAA) and specify the authentication method list. A method list describes the sequence and
authentication method to be queried to authenticate a user.
The AAA process begins with authentication. When 802.1x port-based authentication is enabled and the client
supports 802.1x-compliant client software, these events occur:
•
If the client identity is valid and the 802.1x authentication succeeds, the switch grants the client access
to the network.
•
If 802.1x authentication times out while waiting for an EAPOL message exchange and MAC
authentication bypass is enabled, the switch can use the client MAC address for authorization. If the
client MAC address is valid and the authorization succeeds, the switch grants the client access to the
network. If the client MAC address is invalid and the authorization fails, the switch assigns the client
to a guest VLAN that provides limited services if a guest VLAN is configured.
•
If the switch gets an invalid identity from an 802.1x-capable client and a restricted VLAN is specified,
the switch can assign the client to a restricted VLAN that provides limited services.
•
If the RADIUS authentication server is unavailable (down) and inaccessible authentication bypass is
enabled, the switch grants the client access to the network by putting the port in the critical-authentication
state in the RADIUS-configured or the user-specified access VLAN.
Inaccessible authentication bypass is also referred to as critical authentication or the
AAA fail policy.
Note
If Multi Domain Authentication (MDA) is enabled on a port, this flow can be used with some exceptions that
are applicable to voice authorization.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
264 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Port-Based Authentication Process

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
