Cisco Catalyst 2960-X User Manual

PurposeCommand or Action
Specifies an active VLAN as an 802.1x restricted VLAN.
The range is 1 to 4094.
authentication event fail action authorize vlan vlan-id
Example:
Switch(config-if)# authentication event fail
Step 5
You can configure any active VLAN except an internal
VLAN (routed port), an RSPAN VLAN or a voice VLAN
as an 802.1x restricted VLAN.
action authorize vlan 2
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 6
Configuring Number of Authentication Attempts on a Restricted VLAN
You can configure the maximum number of authentication attempts allowed before a user is assigned to the
restricted VLAN by using the authentication event retry retry count interface configuration command. The
range of allowable authentication attempts is 1 to 3. The default is 3 attempts.
Beginning in privileged EXEC mode, follow these steps to configure the maximum number of allowed
authentication attempts. This procedure is optional.
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
Use one of the following:
•
switchport mode access
•
switchport mode private-vlan host
4.
authentication port-control auto
5.
authentication event fail action authorize vlan vlan-id
6.
authentication event retry retry count
7.
end
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
326 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring a Restricted VLAN

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
