Cisco Catalyst 2960-X User Manual

PurposeCommand or Action
Returns to privileged EXEC mode.exit
Step 4
Verifies your settings.show ip arp inspection vlan
vlan-range
Step 5
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 6
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config
Step 7
startup-config
Monitoring DAI
To monitor DAI, use the following commands:
DescriptionCommand
Clears dynamic ARP inspection statistics.clear ip arp inspection statistics
Displays statistics for forwarded, dropped, MAC
validation failure, IP validation failure, ACL permitted
and denied, and DHCP permitted and denied packets
for the specified VLAN. If no VLANs are specified
or if a range is specified, displays information only
for VLANs with dynamic ARP inspection enabled
(active).
show ip arp inspection statistics [vlan vlan-range]
Clears the dynamic ARP inspection log buffer.clear ip arp inspection log
Displays the configuration and contents of the
dynamic ARP inspection log buffer.
show ip arp inspection log
For the show ip arp inspection statistics command, the switch increments the number of forwarded packets
for each ARP request and response packet on a trusted dynamic ARP inspection port. The switch increments
the number of ACL or DHCP permitted packets for each packet that is denied by source MAC, destination
MAC, or IP validation checks, and the switch increments the appropriate.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 259
Configuring Dynamic ARP Inspection
Monitoring DAI

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
