Cisco Catalyst 6807-XL User Manual

•
WS-X6848-SFP-2T and WS-X6848-SFP-2TXL
•
WS-X6716-10T
•
WS-X6816-10T-2T and WS-X6816-10T-2TXL
•
WS-X6716-10G
•
WS-X6816-10G-2T and WS-X6816-10G-2TXL
•
WS-X6724-SFP
•
WS-X6824-SFP-2T and WS-X6824-SFP-2TXL
•
WS-X6904-40G-2T and WS-X6904-40G-2TXL
The switch supports the following Cisco Catalyst 6500 Series service modules:
•
NAM3
•
ASA-SM
•
WiSM2
•
ACE-30
For more information, see the Catalyst 6500 Ethernet Module Installation Guide.
Related Topics
Installing Transceivers and Module Connectors, on page 47
Pluggable Transceivers, on page 79
Module Connectors, on page 84
Cable Specifications, on page 88
Fan Tray
The switch supports a single front-serviceable and hot-swappable fan tray with nine individual fans. The fan
tray is responsible for cooling the entire chassis and interfacing with environmental monitors to trigger alarms
when conditions exceed thresholds.
The fan tray supports:
•
Model number C6807-XL-FAN.
•
A maximum cooling capacity of 850 CFM
1
(120 CFM per slot). At this capacity, the fan tray can cool
seven 800 W modules.
•
Four variable-speed operating modes between 3,000 and 6,000 RPM
2
for each fan.
•
Up to three fan failures. The fans that are working increase RPM or CFM.
•
Online Insertion and Removal (OIR) for a minimum of 120 seconds (depending on the ambient
temperature).
1
Cubic feet per minute.
2
Revolutions per minute.
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
4 OL-30656-01
Product Overview
Fan Tray
