Step 2
Grasp the power supply latch and pull to slide the power supply part of the way out of the chassis. Place your
other hand underneath the power supply, and slide the power supply clear out of the chassis.
Step 3
If the power supply bay is to remain empty:
a) Install a blank (Cisco part number C6800-PS-CVR=), which is a part of the accessory kit, over the opening.
b) (Optional) Remove the corresponding power cord by loosening the cable clamp and then detaching the
power cord.
Removing and Installing the Fan Tray
This section describes how to remove and install the fan tray.
The fan tray is designed to be removed and installed while the system is operating (powered on) without
presenting an electrical hazard or damage to the system.
Note
Related Topics
Fan Tray, on page 4
Air Flow, on page 15
Fan Tray LED, on page 8
Installing the Fan Tray
To install the new fan tray, perform these steps:
Procedure
Step 1
Remove the fan tray from its packaging.
Step 2
Hold the fan tray handle with one hand. Place your other hand underneath the fan tray. (The correct position
involves the fan tray LEDs being on top).
Step 3
Place the fan module into the front of the fan tray bay so that it rests on the chassis, lift the fan module up
slightly to align it with the top and bottom of the bay, and then push the fan module into the chassis until it
sits in the backplane. The fan module willl snap in.
What to Do Next
Check that the new fan assembly is installed correctly. For more information, see Checking Fan Tray
Installation.
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
54 OL-30656-01
Removing and Replacing FRUs
Removing and Installing the Fan Tray
