Table 12: Rack-Mount Kit Contents and Description
DescriptionQuantityPart
Is attached to the rack posts to form a shelf for the switch
chassis to rest on.
2Shelf bracket
Is attached between the two side rack-mount brackets to
secure them together.
1Cross Bar bracket
Secures the brackets to a rack that requires 12-24 screws
(Five for each L bracket).
1012-24 x 0.75-inch Phillips binding
head screw
Secures the brackets to a rack that requires 10-32 screws
(Five for each L bracket).
1010-32 x 0.75-inch Phillips binding
head screw
Secures the crossbar bracket to the rack-mount side brackets.2M3 x 8 mm Phillips pan head
screw
Note
•
This rack-mount shelf kit is not suitable for use with racks that have obstructions (such as power
strips) because the obstructions could impair access to switch FRUs.
•
On many older equipment racks, the rack posts are prethreaded to accept either 10-32 or 12-24
screws. Newer rack enclosure posts might not be prethreaded. These rack-enclosure posts require
that you install 10-32 or 12-24 clip nuts or cage nuts to secure the rack-mount screws. The clip nuts
or cage nuts are not included as part of the accessory kit and must be obtained on your own.
Determine the clearance between the insides of the left and right rails of your rack system and install the shelf
brackets accordingly.
Installing the Shelf and Crossbar Brackets in a 17.5-inch (44.45 cm) Opening
You have to rear-mount the shelf and crossbar brackets for a rack with a 17.5-inch rail-to-rail opening.Important
Perform these steps:
Before You Begin
You will require:
•
Number 1 and Number 2 Phillips screwdrivers
•
3/16-inch flat-blade screwdriver
•
Tape measure and level
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
34 OL-30656-01
Installing the Switch
Installing the Shelf and Crossbar Brackets in a 17.5-inch (44.45 cm) Opening
