Cisco Catalyst 6807-XL User Manual

Installing the Shelf and Crossbar Brackets in a 17.75 inch (45.09 cm) Opening
You have to front-mount the shelf and cross bar brackets for a rack with a 17.75-inch rail-to-rail opening.Important
Perform these steps:
Before You Begin
You will require:
•
Number 1 and Number 2 Phillips screwdrivers
•
3/16-inch flat-blade screwdriver
•
Tape measure and level
Procedure
Step 1
Position the support flange of the left shelf bracket on the front of the left rail. Align and secure the bracket
to the rack by using two EA screws.
Step 2
Position the support flange of the right shelf bracket on the front of the right rail (make sure that it is level
with the left shelf bracket). Align and secure the bracket to the rack by using two EA screws.
Step 3
Position the crossbar bracket to the rear of the shelf brackets Align and secure the crossbar bracket to the shelf
bracket with one M3 screw on each side.
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
36 OL-30656-01
Installing the Switch
Installing the Shelf and Crossbar Brackets in a 17.75 inch (45.09 cm) Opening
