Individual fans are not field-replaceable units (FRUs). You must replace the fan tray.Note
Related Topics
Removing and Installing the Fan Tray, on page 54
Troubleshooting the Fan Tray, on page 105
Fan Tray LED, on page 8
Power Supply Module
The switch supports one to four field-replaceable power supply modules (PSMs) labeled 1 to 4, with a single
system On/Off switch.
The PSM supports:
•
Model number C6800-XL-3KW-AC.
•
Redundant and combined configuration modes. The redundant mode is the default and recommended
mode.
•
Only AC input.
•
3000 W when powered with 240VAC, and 1300 W when powered with 120VAC.
•
Only single-phase source AC. Source AC can be out of phase between multiple power supplies or
multiple AC-power plugs on the same power supply because all AC power supply inputs are isolated.
This table describes the available power supply configuration modes:
Table 2: PSM Configuration Modes
Combined Mode (n+0)Redundant Mode (n+1)
The system operates on one to four power
supplies. The power available to the
system is the sum of power outputs of all
the PSMs in the chassis.
The system operates on two to four PSMs. This
includes a reserve PSM that is available in case
of a failure. The system power supply
configuration is n
3
PSMs +1 redundant PSM.
Description
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
OL-30656-01 5
Product Overview
Power Supply Module
