AC Power Supplies
The C8300-1N1S-4T2X|6T devices have two different AC power supply types and they are the same physical
size. The C8300-2N2S-4T2X|6Tdevices also have two AC power supply types and they are of the same
physical size but they are not the same size as those in the C8300-1N1S-4T2X|6T. The power supplies cannot
be interchanged.
Overview of the AC Power Supply
The AC power supplies for C8300-1N1S-4T2X|6T devices are as follows. The two supplies are physically
similar and a diagram is shown in the figure below.
• PWR-CC1-250WAC
• PWR-CC1-500WAC
Figure 40: 250W/500W AC Power Supply for C8300-1N1S-4T2X|6T
ModuleSl. No
PSU11
PSU02
Hardware Installation Guide for Cisco Catalyst 8300 Series Edge Platforms
64
Install Internal Components and Field Replaceable Units
AC Power Supplies
