CITROEN C5 2008 User Manual

178
VI
2
3
1
2
3
1
2
DIESEL ENGINE HDi 173 FAP
It is essential to remove the very cold protection:
When the outside temperature exceeds 10 °C.
When driving at speeds of over 120 km/h (approximately
75 mph).
•
•
V E RY C O L D P R O T E C T I O N
DIESEL ENGINE
V6 HDi 208 FAP
Snow situation
Slide the defl ector
1
into the air
duct
2
and clip in.
Moveable device which prevents
the intake of snow particles, which
could obstruct the air fi lter.
Snow situation
Push and rotate the knob
1
by 90 °
in the direction of the arrow in order
to position the shutter
2
in a verti-
cal position in the air duct
3
.
Note :
To return to the normal situ-
ation, push the knob
1
then rotate
in the opposite direction.
Normal situation
The shutter
2
is in a horizontal
position in the air duct
3
.
