Clarion NX501E Owner's Manual & Installation Manual

57NX501E/NZ501E
English
English
Owner’s Manual
25. SPECIFICATIONS
FM Tuner
FrequencyRange: 87.5 MHz to 108.0 MHz
UsableSensitivity:8 dBµV
50dBQuietingSensitivity: 14 dBµV
AlternateChannelSelectivity: 70 dB
StereoSeparation: 25 dB (1 kHz)
FrequencyResponse: 30 Hz to 14 kHz
AM Tuner
FrequencyRange: 531 kHz to 1,602 kHz
UsableSensitivity: 30 dBµV
DVD Player System
Digital Versatile Disc System with CDDA capable
Usablediscs:
DVD video disc, Compact disc
FrequencyResponse: 20 Hz to 20 kHz
Sound/NoiseRatio:95 dbA (1 W Ref)
DynamicRange: 95 dB (1 kHz)
Distortion:0.05%
Videosystem:NTSC/PAL
Audio/Video Input
Audioinputvoltage:
≤
2 V
rms
Videoinputvoltage: 1.0 V
p-p
@75
Audioinputsensitivity(at2Voutput)
High: 325 mV
rms
Mid: 650 mV
rms
Low: 1.3 V
rms
Audio/Video output
Videooutputvoltage:1.0 V
p-p
@75
NX501EScreenSize: 6.2” wide type
Pixels: 1,152,000
Resolution: 800 x 480 x 3 (RGB)
NZ501EScreenSize: 7” wide type
Pixels: 1,152,000
Resolution: 800 x 480 x 3 (RGB)
Bluetooth
Specication: Bluetooth Ver 2.1+EDR
Prole: HFP1.5(Hands Free Profile)
HSP1.0 (Headset Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP1.2,1.3,1.4 (AV Remote Control Profile)
PowerClass: 2
MP3 mode
Bitrate: 32 kbps to 320 kbps
Samplingrate: 32 kHz, 44.1 kHz, 48 kHz
WMA mode
Bitrate:64 kbps to 192 kbps
Samplingrate: 32 kHz, 44.1 kHz, 48 kHz
USB
Specication:USB 1.1/2.0 (FS)
Playableaudioformat:
 MP3(.mp3):MPEG2/AudioLayer-3
 WMA(.wma):Ver7/8/9.1/9.2
Playable Video Format
DiscVideo:.mp4(MPEG4/AAC)720*480
.avi (MPEG4/MP3) 720*480
.mpg (MPEG2/MP3) 720*480
USBVideo:.mp4(MPEG4/AAC)480*272
.mp4 (H.264/AAC) 480*272
.3gp (MPEG4/AAC) 480*272
.avi (MPEG4/MP3) 480*272
.mpg (MPEG2/MP3) 480*272
General
Powersourcevoltage:
14.4 VDC (10.8 to 15.6 V allowable)
Ground:Negative
Currentconsumption:4.0 A @1 W
AutoAntennaRatedCurrent: 500 mA less
Note:
•SpecicationscomplywithJEITAStandards.
•Specicationsanddesignaresubjecttochange
without notice for further improvement.
Downloaded from Caradio-Manual.com Manuals

Clarion NX501E Specifications

General

MP3 playback	Yes
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Product color	Black
Audio output channels	4.0 channels
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.2 \
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
I/O ports	1x USB 2x A/V In
