Clarion NX501E Owner's Manual & Installation Manual

59NX501E/NZ501E
English
English
Owner’s Manual
INSTALLATION / WIRE
CONNECTION GUIDE
1. Before Starting
1. This set is exclusively for use in cars with a negative ground
12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “-” terminal before starting.
This is to prevent short circuits during installation. (Figure 1)
2. Package Contents
Main unit ................................................... 1
Wiring harness .......................................... 1
GPS antenna ............................................ 1
Clamp for GPS antenna's cable ............... 3
Double face tape for GPS Antenna .......... 1
Remote control unit .................................. 1
Battery (CR2025) ...................................... 1
(Installed in remote control)
Trim ring ................................................... 1
Cleaning cloth........................................... 1
Warranty Card .......................................... 1
Owner’s manual and
Installation manual.................................... 2
User manual - Clarion mobile map............2
Electro tap ................................................ 2
2DIN trim ring 200mm wide
(NX501E only) ........................................... 1
Mounting Bracket key
(NZ501E only) ........................................... 2
Flush mount bolts
(NX501E) ................................................... 8
(NZ501E) ................................................... 4
Hexagon Head Screw
(NX501E) ................................................... 8
(NZ501E) ................................................... 5
AV cable ................................................... 1
Line out cable (NX501E only) ................... 1
Line in cable (NX501E only) ...................... 1
Rear Zone out cable (NX501E only) ......... 1
SWI cable (NX501E only) .......................... 1
DTV cable (NX501E only).......................... 1
External Microphone cable
(NX501E only) ........................................... 1
CONTENTS
1. Before Starting ..............................................................................................59
2. Package Contents .........................................................................................59
3. General Cautions...........................................................................................60
4. Cautions On Installation ................................................................................60
5. Installing The Main Unit .................................................................................61
6. Cautions On Wiring .......................................................................................63
7. Wire Connections ..........................................................................................64
Figure 1
Car battery
Downloaded from Caradio-Manual.com Manuals

Clarion NX501E Specifications

General

MP3 playback	Yes
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Product color	Black
Audio output channels	4.0 channels
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.2 \
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
I/O ports	1x USB 2x A/V In
