ID-FLX Lite & Telecom Global Guide
49
Press FAULT RESET accepts all alarms. Non-active alarms immediately disappear from the list. Active alarm
list appears on the screen when a new alarm comes up and Main MEASUREMENT screen is active.
Note: Alarm list does not activate when you are reviewing the values or setpoints.
The second alarm list for ECU alarms is also available. It is displayed one screen above the standard alarm list
on the controller display or under the standard alarm list in Control window of LiteEdit. If an alarm appears in this
alarm list, it is signalized in the standard alarm list and by exclamation mark on the main measure screen.
Control from the front panel
↑↓ One screen up/down
Enter Cursor move within the ECU alarm list
Enter + Fault reset ECU fault code reset
5.12 How to list History records?
1. Use repeatedly PAGE button to select the History menu.
2. Use ↑ or ↓ to select requested History line.
3. Press ENTER to go-on line to right.
4. Use repeatedly PAGE button to go back to Measurement screen.
5.13 MEASUREMENT screens description
5.13.1 Main measure screen
Operation mode of the engine
Indication: “L” = Access lock, “!” = active Alarm
Status of the engine
Run hrs - events counting Running hours of the engine
Timer - events counting time (e.g. prestart, cooling, etc.)
Engine RPM
