DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Parameter Description
From/To
A consecutive group of ports may be configured starting with the selected port.
Type
This drop-down menu allows you to select between RX (receive,) TX (transmit,) and
Both. This setting will determine whether the bandwidth ceiling is applied to receiving,
transmitting, or both receiving and transmitting packets.
No Limit
This drop-down menu allows you to specify that the selected port will have no
bandwidth limit. Enabled disables the limit.
Rate
This field allows you to enter the data rate, in Kbit/s, that will be the limit for the
selected port. The user may choose a rate between 64 and 1024000 Kbit/s.
Click Apply to set the bandwidth control for the selected ports. Results of configured Bandwidth Settings will be displayed in
the Port Bandwidth Table.
802.1p Default Priority
The Switch allows the assignment of a default 802.1p priority to each port on the Switch. In the CoS folder, click 802.1p Default
Priority, to view the window shown below.
Figure 8- 3. 802.1p Default Priority window
This window allows you to assign a default 802.1p priority to any given port on the Switch. The priority tags are numbered from
0, the lowest priority, to 7, the highest priority. To implement a new default priority choose a port range by using the From and
To pull-down menus and then insert a priority value, from 0 to 7 in the Priority field. Click Apply to implement your settings.
103
