DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
SNMP View Table
This window is used to assign views to community strings that define which MIB objects can be accessed by a remote SNMP
manager. To view the SNMP View Table window, open the SNMP Manager folder under Administration and click the SNMP
View Table entry. The following window should appear:
Figure 6- 31. SNMP View Table window
To delete an existing SNMP View Table entry, click the
in the Delete column corresponding to the entry to delete. To create a
new entry, click the Add button and a separate window will appear.
Figure 6- 32. SNMP View Table Configuration window
The SNMP Group created with this table maps SNMP users (identified in the SNMP User Table) to the views created in the
previous window.
The following parameters can set:
Parameter Description
View Name
Type an alphanumeric string of up to 32 characters. This is used to identify the new SNMP
view being created.
Subtree OID
Type the Object Identifier (OID) Subtree for the view. The OID identifies an object tree (MIB
tree) that will be included or excluded from access by an SNMP manager.
View Type
Select Included to include this object in the list of objects that an SNMP manager can
access. Select Excluded to exclude this ob
