DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
5) AuthControlledPortControl set to ForceUnauthorized
6) Port re-initialization
7) Port Administratively Disabled
8) Not Terminated Yet
Octets Rx
The number of octets received in user data frames on this port during the session.
Octets Tx
The number of octets transmitted in user data frames on this port during the session.
ID
A unique identifier for the session, in the form of a printable ASCII string of at least three
characters.
Authentic Method
The authentication method used to establish the session. Valid Authentic Methods include:
(1) Remote Authentic Server - The Authentication Server is external to the Authenticator’s
System.
(2) Local Authentic Server - The Authentication Server is located within the Authenticator’s
System.
Auth Statistics
This table contains the statistics objects for the Authenticator PAE associated with each port. An entry appears in this table for
each port that supports the Authenticator function. To view the Authenticator Statistics, click Monitoring > Port Access Control
> Auth Statistics.
Figure 11- 27. Authenticator Statistics window
The user may select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. The
default value is one second.
199
