DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Local Users
In the Security folder, open the 802.1x folder and click 802.1X User to open the 802.1x User window. This window will allow
the user to set different local users on the Switch.
Figure 10- 21. Local Users Configuration window
Enter a User Name, Password and confirmation of that password. Properly configured local users will be displayed in the Local
Users Table at the bottom of the same window.
Initializing Ports for Port Based 802.1x
Existing 802.1x port and MAC settings are displayed and can be configured using the window below.
Click Security > 802.1x > Initialize Port(s) to open the following window:
Figure 10- 22. Initialize Port window
This window allows initialization of a port or group of ports. The Initialize Port Table in the bottom half of the window displays
the current status of the port(s).
This window displays the following information:
Parameter Description
From and To
Select ports to be initialized.
Auth PAE State
The Authenticator PAE State will display one of the following: Initialize, Disconnected,
To Next Page
