DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Upload Log
The following window is used to upload log files from SIM member switches to a specified PC. To view this window click
Administration > Single IP Management > Upload Log File. To upload a log file, enter the IP address of the SIM member
switch and then enter a path on your PC where you wish to save this file. Click Upload to initiate the file transfer.
Figure 6- 60. Upload Log File window
Forwarding & Filtering
Unicast Forwarding
Open the Forwarding Filtering folder in the Configuration menu and click on the Unicast Forwarding link. This will open the
following window:
Figure 6- 61. Unicast Forwarding window
To add or edit an entry, define the following parameters and then click Add/Modify:
Parameter Description
VID
The VLAN ID number of the VLAN on which the above Unicast MAC address resides.
MAC Address
The MAC address to which packets will be statically forwarded. This must be a unicast
MAC address.
Port
Allows the selection of the port number on which the MAC address entered above resides.
Click Apply to implement the changes made. To delete an entry in the Static Unicast Forwarding Table, click the corresponding X
under the Delete heading.
70
