DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
MAC Notification Settings
Figure 6- 19. MAC Notification Settings window
Select a port
TFTP Services
Figure 6- 20. TFTP Services window
MAC Notification is used to monitor MAC addresses learned and
entered into the forwarding database. To globally set MAC notification
on the Switch, open the following window by opening the MAC
Notification Settings in the Administration folder.
Global Settings
The following parameters may be viewed and modified:
Parameter Description
State
Enable or disable MAC notification globally on the
Switch
Interval
(sec)
The time in seconds between notifications.
History
Size
The maximum number of entries listed in the
history log used for notification. Up to 500 entries
can be specified.
Port Settings
To change MAC notification settings for a port or group of ports on the
Switch, configure the following parameters.
Parameter Description
From…To
or group of ports to enable for MAC
notification using the pull-down menus.
State
Enable MAC Notification for the ports selected
using the pull-down menu.
Click Apply to implement changes made.
Trivial File Transfer Protocol (TFTP)
services allow the Switch's firmware to
firmware file from a TFTP server to the
Switch. A configuration file can also be
loaded into the Switch from a TFTP
server. Switch settings can be saved to
the TFTP server, and a history log can be
uploaded from the Switch to the TFTP
server. The TFTP server must be running
TFTP server software to perform the file
transfer.
42
