DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Auth Session Statistics
This table contains the session statistics objects for the Authenticator PAE associated with each port. An entry appears in this table
for each port that supports the Authenticator function. To view the Authenticator Session Statistics, click Monitoring > Port
Access Control > Auth Session Statistics.
Figure 11- 26. Authenticator Session Counter window
The user may select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. The
default value is one second.
The following fields can be viewed:
Parameter Description
Port
The identification number assigned to the Port by the System in which the Port resides.
Frames Rx
The number of user data frames received on this port during the session.
Frames Tx
The number of user data frames transmitted on this port during the session.
UserName
The User-Name representing the identity of the Supplicant PAE.
Time
The duration of the session in seconds.
Terminate Cause
The reason for the session termination. There are eight possible reasons for termination.
1) Supplicant Logoff
2) Port Failure
3) Supplicant Restart
4) Reauthentication Failure
198
